STGF15H60DF
STMicroelectronics
STMicroelectronics
IGBT 600V 30A 30W TO220FP
$1.89
Available to order
Reference Price (USD)
1+
$2.44000
50+
$2.08880
100+
$1.80050
500+
$1.50440
1,000+
$1.27068
2,500+
$1.19276
5,000+
$1.17978
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Maximize energy efficiency with STGF15H60DF Single IGBTs by STMicroelectronics, a trusted name in discrete semiconductors. Suitable for solar inverters, motor controllers, and more, these transistors feature low conduction loss and high switching frequency. Their robust design ensures long-term performance even in harsh environments. Choose STGF15H60DF for your next project and experience the STMicroelectronics difference. Submit your inquiry today for expert assistance!
Specifications
- Product Status: Active
- IGBT Type: Trench Field Stop
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 30 A
- Current - Collector Pulsed (Icm): 60 A
- Vce(on) (Max) @ Vge, Ic: 2V @ 15V, 15A
- Power - Max: 30 W
- Switching Energy: 136µJ (on), 207µJ (off)
- Input Type: Standard
- Gate Charge: 81 nC
- Td (on/off) @ 25°C: 24.5ns/118ns
- Test Condition: 400V, 15A, 10Ohm, 15V
- Reverse Recovery Time (trr): 103 ns
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3 Full Pack
- Supplier Device Package: TO-220FP
