FGH60N60SMD-F085
onsemi
onsemi
IGBT 600V 120A 600W TO247
$7.08
Available to order
Reference Price (USD)
1+
$7.00000
10+
$6.34600
450+
$5.06927
900+
$4.64343
1,350+
$4.07568
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The FGH60N60SMD-F085 Single IGBT from onsemi redefines reliability in power electronics. Tailored for renewable energy, telecom, and defense applications, it offers ultra-low switching losses and high-frequency operation. With anti-parallel diodes and short-circuit ratings, it s built for safety and performance. onsemi stands behind every FGH60N60SMD-F085 with unmatched customer service. Start your order process by contacting our sales team today!
Specifications
- Product Status: Obsolete
- IGBT Type: Field Stop
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 120 A
- Current - Collector Pulsed (Icm): 180 A
- Vce(on) (Max) @ Vge, Ic: 2.5V @ 15V, 60A
- Power - Max: 600 W
- Switching Energy: 1.59mJ (on), 390µJ (off)
- Input Type: Standard
- Gate Charge: 280 nC
- Td (on/off) @ 25°C: 22ns/116ns
- Test Condition: 400V, 60A, 3Ohm, 15V
- Reverse Recovery Time (trr): 42 ns
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247-3
