TLP291(GB,SE
Toshiba Semiconductor and Storage
Toshiba Semiconductor and Storage
OPTOISOLATOR 3.75KV TRANS 4-SO
$0.44
Available to order
Reference Price (USD)
1+
$0.47000
10+
$0.33000
25+
$0.28600
175+
$0.22000
350+
$0.17874
525+
$0.13200
1,050+
$0.11000
2,625+
$0.09900
5,075+
$0.09350
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Maximize your system's efficiency with TLP291(GB,SE Optoisolators by Toshiba Semiconductor and Storage, designed for Photovoltaic Output applications. These isolators are perfect for isolating digital signals, protecting microcontrollers, and ensuring safe operation in high-voltage environments. Suitable for consumer electronics, aerospace, and defense applications, they deliver consistent performance under extreme conditions. Get started today contact us for more details and a customized solution!
Specifications
- Product Status: Active
- Number of Channels: 1
- Voltage - Isolation: 3750Vrms
- Current Transfer Ratio (Min): 100% @ 5mA
- Current Transfer Ratio (Max): 600% @ 5mA
- Turn On / Turn Off Time (Typ): 3µs, 3µs
- Rise / Fall Time (Typ): 2µs, 3µs
- Input Type: DC
- Output Type: Transistor
- Voltage - Output (Max): 80V
- Current - Output / Channel: 50mA
- Voltage - Forward (Vf) (Typ): 1.25V
- Current - DC Forward (If) (Max): 50 mA
- Vce Saturation (Max): 300mV
- Operating Temperature: -55°C ~ 110°C
- Mounting Type: Surface Mount
- Package / Case: 4-SOIC (0.179", 4.55mm Width)
- Supplier Device Package: 4-SO
