STGWA40M120DF3
STMicroelectronics
STMicroelectronics
IGBT 1200V 80A 468W TO-247-3
$6.96
Available to order
Reference Price (USD)
1+
$12.11000
30+
$10.54133
120+
$9.26550
510+
$8.17875
1,020+
$7.23375
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover high-performance STGWA40M120DF3 Single IGBTs from STMicroelectronics, designed for efficient power management in various industrial applications. These transistors offer superior switching capabilities and thermal performance, making them ideal for motor drives, renewable energy systems, and power supplies. Features include low saturation voltage, high current capacity, and robust construction. Whether you're upgrading existing systems or designing new solutions, STGWA40M120DF3 ensures reliability and efficiency. Contact us today for pricing and technical support!
Specifications
- Product Status: Active
- IGBT Type: Trench Field Stop
- Voltage - Collector Emitter Breakdown (Max): 1200 V
- Current - Collector (Ic) (Max): 80 A
- Current - Collector Pulsed (Icm): 160 A
- Vce(on) (Max) @ Vge, Ic: 2.3V @ 15V, 40A
- Power - Max: 468 W
- Switching Energy: 1.03mJ (on), 480µJ (off)
- Input Type: Standard
- Gate Charge: 125 nC
- Td (on/off) @ 25°C: 35ns/140ns
- Test Condition: 600V, 40A, 10Ohm, 15V
- Reverse Recovery Time (trr): 355 ns
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247 Long Leads
