M80-5000000M2-02-PM1-00-000

Specifications

• Product Status: Active
• Connector Type: Header
• Contact Type: Male Pin, Power
• Pitch - Mating: 0.157" (4.00mm)
• Number of Positions: 2
• Number of Rows: 1
• Row Spacing - Mating: -
• Number of Positions Loaded: All
• Style: Board to Cable/Wire
• Shrouding: Shrouded - 4 Wall
• Mounting Type: Through Hole
• Termination: Solder
• Fastening Type: Threaded
• Contact Length - Mating: -
• Contact Length - Post: 0.138" (3.50mm)
• Overall Contact Length: -
• Insulation Height: 0.220" (5.60mm)
• Contact Shape: Circular
• Contact Finish - Mating: Gold
• Contact Finish Thickness - Mating: 30.0µin (0.76µm)
• Contact Finish - Post: -
• Contact Material: Copper Alloy
• Insulation Material: Polyphenylene Sulfide (PPS), Glass Filled
• Features: Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware
• Operating Temperature: -55°C ~ 125°C
• Ingress Protection: -
• Material Flammability Rating: UL94 V-0
• Insulation Color: Black
• Current Rating (Amps): 40A
• Voltage Rating: 800V
