IXGH56N60A3
IXYS
IXYS
IGBT 600V 150A 330W TO247
$0.00
Available to order
Reference Price (USD)
30+
$5.67000
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Maximize energy efficiency with IXGH56N60A3 Single IGBTs by IXYS, a trusted name in discrete semiconductors. Suitable for solar inverters, motor controllers, and more, these transistors feature low conduction loss and high switching frequency. Their robust design ensures long-term performance even in harsh environments. Choose IXGH56N60A3 for your next project and experience the IXYS difference. Submit your inquiry today for expert assistance!
Specifications
- Product Status: Obsolete
- IGBT Type: PT
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 150 A
- Current - Collector Pulsed (Icm): 370 A
- Vce(on) (Max) @ Vge, Ic: 1.35V @ 15V, 44A
- Power - Max: 330 W
- Switching Energy: 1mJ (on), 3.75mJ (off)
- Input Type: Standard
- Gate Charge: 140 nC
- Td (on/off) @ 25°C: 26ns/310ns
- Test Condition: 480V, 44A, 5Ohm, 15V
- Reverse Recovery Time (trr): -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247AD
