CI2502P1V00-LF
Cvilux USA
Cvilux USA
2 POS 2.50MM (.098) WIRE TO BOAR
$0.11
Available to order
Reference Price (USD)
1+
$0.11000
500+
$0.1089
1000+
$0.1078
1500+
$0.1067
2000+
$0.1056
2500+
$0.1045
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The CI2502P1V00-LF Cvilux USA Rectangular Connectors - Headers, Male Pins offer unmatched reliability for your electronic assembly needs. With features like corrosion resistance, high-temperature tolerance, and easy mating, these connectors are suited for aerospace, medical devices, and more. Trust Cvilux USA for top-tier connectivity solutions. Interested? Get in touch today for pricing and availability!
Specifications
- Product Status: Obsolete
- Connector Type: Header
- Contact Type: Male Pin
- Pitch - Mating: 0.098" (2.50mm)
- Number of Positions: 2
- Number of Rows: 1
- Row Spacing - Mating: -
- Number of Positions Loaded: All
- Style: Board to Cable/Wire
- Shrouding: Shrouded - 4 Wall
- Mounting Type: Through Hole
- Termination: Solder
- Fastening Type: Detent Lock
- Contact Length - Mating: -
- Contact Length - Post: 0.134" (3.40mm)
- Overall Contact Length: 0.350" (8.89mm)
- Insulation Height: 0.232" (5.90mm)
- Contact Shape: Circular
- Contact Finish - Mating: Tin
- Contact Finish Thickness - Mating: 120.0µin (3.05µm)
- Contact Finish - Post: Tin
- Contact Material: Brass
- Insulation Material: Polyamide (PA46), Nylon 4/6
- Features: -
- Operating Temperature: -25°C ~ 85°C
- Ingress Protection: -
- Material Flammability Rating: UL94 V-0
- Insulation Color: Natural
- Current Rating (Amps): 3A
- Voltage Rating: 50VAC
