UC3825ANG4
Texas Instruments

Texas Instruments
IC REG CTRLR MULT TOPOLOGY 16DIP
$0.00
Available to order
Reference Price (USD)
75+
$7.99093
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The UC3825ANG4 by Texas Instruments is a versatile DC DC Switching Controller that delivers exceptional performance in power management. Ideal for applications such as LED lighting, networking hardware, and battery-powered devices, this PMIC voltage regulator offers features like wide input voltage range and fast transient response. Texas Instruments's commitment to quality ensures that the UC3825ANG4 meets the highest industry standards. For more details or to place an order, reach out to our sales team now.
Specifications
- Product Status: Discontinued at Digi-Key
- Output Type: Transistor Driver
- Function: Step-Up, Step-Up/Step-Down
- Output Configuration: Positive
- Topology: Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull
- Number of Outputs: 2
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 8.4V ~ 22V
- Frequency - Switching: 400kHz ~ 1MHz
- Duty Cycle (Max): 50%
- Synchronous Rectifier: No
- Clock Sync: No
- Serial Interfaces: -
- Control Features: Current Limit, Frequency Control, Ramp, Soft Start
- Operating Temperature: 0°C ~ 70°C (TA)
- Mounting Type: Through Hole
- Package / Case: 16-DIP (0.300", 7.62mm)
- Supplier Device Package: 16-PDIP
