TLP701A(F)
Toshiba Semiconductor and Storage
Toshiba Semiconductor and Storage
OPTOISO 5KV GATE DRIVER 6SDIP GW
$0.00
Available to order
Reference Price (USD)
1+
$1.63000
10+
$1.32300
25+
$1.01760
100+
$0.91580
300+
$0.81400
500+
$0.69190
1,000+
$0.56980
2,500+
$0.54131
5,000+
$0.52910
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Discover high-performance Toshiba Semiconductor and Storage TLP701A(F) Gate Driver Isolators designed for seamless signal transmission in power electronics. These isolators feature robust noise immunity, high-speed switching, and reinforced isolation to ensure reliable operation in demanding environments. Ideal for industrial motor drives, solar inverters, and EV charging systems, our Gate Driver Isolators provide the precision and safety your applications require. Contact us today for customized solutions and competitive pricing!
Specifications
- Product Status: Last Time Buy
- Technology: Optical Coupling
- Number of Channels: 1
- Voltage - Isolation: 5000Vrms
- Common Mode Transient Immunity (Min): 20kV/µs
- Propagation Delay tpLH / tpHL (Max): 500ns, 500ns
- Pulse Width Distortion (Max): 350ns
- Rise / Fall Time (Typ): 50ns, 50ns
- Current - Output High, Low: 400mA, 400mA
- Current - Peak Output: 600mA
- Voltage - Forward (Vf) (Typ): 1.57V
- Current - DC Forward (If) (Max): 25 mA
- Voltage - Output Supply: 10V ~ 30V
- Operating Temperature: -40°C ~ 100°C
- Mounting Type: Surface Mount
- Package / Case: 6-SOIC (0.268", 6.80mm Width)
- Supplier Device Package: 6-SDIP Gull Wing
- Approval Agency: cUL, UL
