TLP293(BL-TPL,E
Toshiba Semiconductor and Storage
Toshiba Semiconductor and Storage
OPTOISOLATOR 3.75KV TRANS 4-SO
$0.58
Available to order
Reference Price (USD)
2,500+
$0.15609
5,000+
$0.14190
12,500+
$0.13244
25,000+
$0.12771
62,500+
$0.12298
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Boost your project's reliability with TLP293(BL-TPL,E Optoisolators by Toshiba Semiconductor and Storage, featuring advanced Photovoltaic Output technology. Perfect for use in audio equipment, lighting controls, and instrumentation, these isolators deliver high voltage isolation and low signal distortion. Toshiba Semiconductor and Storage guarantees components that meet rigorous industry standards. Don't wait get in touch today for expert advice and competitive pricing!
Specifications
- Product Status: Active
- Number of Channels: 1
- Voltage - Isolation: 3750Vrms
- Current Transfer Ratio (Min): 200% @ 5mA
- Current Transfer Ratio (Max): 600% @ 5mA
- Turn On / Turn Off Time (Typ): 3µs, 3µs
- Rise / Fall Time (Typ): 2µs, 3µs
- Input Type: DC
- Output Type: Transistor
- Voltage - Output (Max): 80V
- Current - Output / Channel: 50mA
- Voltage - Forward (Vf) (Typ): 1.25V
- Current - DC Forward (If) (Max): 50 mA
- Vce Saturation (Max): 300mV
- Operating Temperature: -55°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 4-SOIC (0.179", 4.55mm Width)
- Supplier Device Package: 4-SO
