SSQ-115-03-G-S
Samtec Inc.
Samtec Inc.
CONN RCPT 15POS 0.1 GOLD PCB
$3.20
Available to order
Reference Price (USD)
1+
$2.86000
10+
$2.74800
25+
$2.51840
50+
$2.40400
100+
$2.28960
250+
$2.00340
500+
$1.94616
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Trust SSQ-115-03-G-S Samtec Inc. Rectangular Connectors - Headers, Receptacles, and Female Sockets for your critical connections. Featuring rugged construction, high-temperature resistance, and quick-disconnect options, they are perfect for heavy-duty use. Suitable for marine, oil & gas, and other challenging environments. Inquire now for expert advice and competitive pricing!
Specifications
- Product Status: Active
- Connector Type: Receptacle
- Contact Type: Forked
- Style: Board to Board or Cable
- Number of Positions: 15
- Number of Positions Loaded: All
- Pitch - Mating: 0.100" (2.54mm)
- Number of Rows: 1
- Row Spacing - Mating: -
- Mounting Type: Through Hole
- Termination: Solder
- Fastening Type: Push-Pull
- Contact Finish - Mating: Gold
- Contact Finish Thickness - Mating: 20.0µin (0.51µm)
- Insulation Color: Black
- Insulation Height: 0.335" (8.51mm)
- Contact Length - Post: 0.394" (10.00mm)
- Operating Temperature: -55°C ~ 125°C
- Material Flammability Rating: UL94 V-0
- Contact Finish - Post: Gold
- Mated Stacking Heights: -
- Ingress Protection: -
- Features: -
- Current Rating (Amps): -
- Voltage Rating: 465VAC, 655VDC
