PS9307AL2-V-E3-AX
Renesas Electronics America Inc
Renesas Electronics America Inc
HI-SPD OPTOCPLR 6PIN SDIP
$1.60
Available to order
Reference Price (USD)
1+
$1.60320
500+
$1.587168
1000+
$1.571136
1500+
$1.555104
2000+
$1.539072
2500+
$1.52304
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Experience next-level isolation with Renesas Electronics America Inc PS9307AL2-V-E3-AX Gate Driver Isolators, designed for precision and reliability. Featuring fast response times, high dielectric strength, and ESD protection, these isolators excel in motor control, power supplies, and telecom infrastructure. Partner with us for tailored solutions send your inquiry now!
Specifications
- Product Status: Active
- Technology: Optical Coupling
- Number of Channels: 1
- Voltage - Isolation: 5000Vrms
- Common Mode Transient Immunity (Min): 50kV/µs
- Propagation Delay tpLH / tpHL (Max): 150ns, 150ns
- Pulse Width Distortion (Max): 50ns
- Rise / Fall Time (Typ): 6ns, 7ns
- Current - Output High, Low: 400mA, 400mA
- Current - Peak Output: 600mA
- Voltage - Forward (Vf) (Typ): 1.56V
- Current - DC Forward (If) (Max): 25 mA
- Voltage - Output Supply: 10V ~ 30V
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 6-SOIC (0.268", 6.80mm Width)
- Supplier Device Package: 6-SDIP Gull Wing
- Approval Agency: CSA, SEMKO, UL, VDE
