PC95PQ65/44-Z
TDK Corporation
TDK Corporation
FERRITE CORE PQ 15.5UH 2PC SET
$54.69
Available to order
Reference Price (USD)
1+
$52.09000
10+
$46.30000
30+
$38.19767
60+
$37.04000
120+
$32.41000
270+
$30.09500
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Enhance your circuit efficiency with TDK Corporation PC95PQ65/44-Z Ferrite Cores, engineered for high-frequency applications and minimal energy loss. These cores are indispensable in power inductors, common-mode chokes, and broadband transformers. Their robust construction ensures durability and consistent performance. Suitable for renewable energy systems, automotive electronics, and more. Don't compromise on quality reach out to our sales team for personalized solutions and competitive pricing!
Specifications
- Product Status: Active
- Core Type: PQ
- Supplier Device Package: PQ 65 x 44
- Material: PC95
- Diameter: -
- Inductance Factor (Al): 15.5 µH
- Tolerance: ±25%
- Gap: Ungapped
- Effective Permeability (µe): -
- Initial Permeability (µi): -
- Core Factor (ΣI/A) mm-1: 0.17
- Effective Length (le) mm: 103
- Effective Area (Ae) mm²: 604
- Minimum Core Cross Section (Amin) mm²: -
- Effective Magnetic Volume (Ve) mm³: 62460
- Finish: Uncoated
- Height: 1.713" (43.50mm)
- Length: 2.559" (65.00mm)
- Width: 1.772" (45.00mm)
