PC0503-220M-RC
Allied Components International
Allied Components International
22uH +/-20% Power Chip Inductor
$0.98
Available to order
Reference Price (USD)
1+
$0.98000
500+
$0.9702
1000+
$0.9604
1500+
$0.9506
2000+
$0.9408
2500+
$0.931
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Boost your circuit efficiency with PC0503-220M-RC Fixed Inductors from Allied Components International, a trusted name in electronic components. Designed with high-frequency capabilities, minimal eddy current losses, and excellent shielding, these inductors are perfect for wireless charging, LED lighting, and automation systems. PC0503-220M-RC ensures peak performance. Looking for tailored solutions? Contact us for expert advice!
Specifications
- Product Status: Active
- Type: Wirewound
- Material - Core: -
- Inductance: 22 µH
- Tolerance: ±20%
- Current Rating (Amps): 1.5 A
- Current - Saturation (Isat): -
- Shielding: Unshielded
- DC Resistance (DCR): 220mOhm Max
- Q @ Freq: -
- Frequency - Self Resonant: -
- Ratings: -
- Operating Temperature: -40°C ~ 85°C
- Inductance Frequency - Test: 2.52 MHz
- Features: -
- Mounting Type: Surface Mount
- Package / Case: Nonstandard
- Supplier Device Package: -
- Size / Dimension: 0.228" L x 0.205" W (5.80mm x 5.20mm)
- Height - Seated (Max): 0.130" (3.30mm)
