MUN5235DW1T1G
onsemi
onsemi
TRANS 2NPN PREBIAS 0.25W SOT363
$0.28
Available to order
Reference Price (USD)
3,000+
$0.04760
6,000+
$0.04161
15,000+
$0.03563
30,000+
$0.03363
75,000+
$0.03164
150,000+
$0.02831
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Introducing onsemi's MUN5235DW1T1G advanced Pre-Biased Transistor Arrays engineered for modern electronics. These BJT arrays provide ready-to-use solutions with internal resistor networks, significantly reducing design complexity and BOM costs. Application highlights include power supply circuits, display drivers, and microcontroller interfaces in automotive, aerospace, and industrial environments. Technical features comprise low VCE(sat), tight current gain matching, and RoHS compliance for environmental safety. onsemi stands behind every MUN5235DW1T1G unit with rigorous quality testing. Streamline your procurement process contact our sales team via the inquiry form for personalized assistance!
Specifications
- Product Status: Active
- Transistor Type: 2 NPN - Pre-Biased (Dual)
- Current - Collector (Ic) (Max): 100mA
- Voltage - Collector Emitter Breakdown (Max): 50V
- Resistor - Base (R1): 2.2kOhms
- Resistor - Emitter Base (R2): 47kOhms
- DC Current Gain (hFE) (Min) @ Ic, Vce: 80 @ 5mA, 10V
- Vce Saturation (Max) @ Ib, Ic: 250mV @ 300µA, 10mA
- Current - Collector Cutoff (Max): 500nA
- Frequency - Transition: -
- Power - Max: 250mW
- Mounting Type: Surface Mount
- Package / Case: 6-TSSOP, SC-88, SOT-363
- Supplier Device Package: SC-88/SC70-6/SOT-363
