IPL1-125-01-S-D-RA-K

Samtec Inc.
IPL1-125-01-S-D-RA-K Preview
Samtec Inc.
CONN HEADER R/A 50POS 2.54MM
$20.79
Available to order
Reference Price (USD)
1+
$12.45000
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram

Specifications

  • Product Status: Active
  • Connector Type: Header
  • Contact Type: Male Pin
  • Pitch - Mating: 0.100" (2.54mm)
  • Number of Positions: 50
  • Number of Rows: 2
  • Row Spacing - Mating: 0.100" (2.54mm)
  • Number of Positions Loaded: All
  • Style: Board to Cable/Wire
  • Shrouding: Shrouded - 4 Wall
  • Mounting Type: Through Hole, Right Angle
  • Termination: Solder
  • Fastening Type: Locking Ramp
  • Contact Length - Mating: 0.215" (5.46mm)
  • Contact Length - Post: 0.085" (2.16mm)
  • Overall Contact Length: -
  • Insulation Height: 0.290" (7.37mm)
  • Contact Shape: Square
  • Contact Finish - Mating: Gold
  • Contact Finish Thickness - Mating: 30.0µin (0.76µm)
  • Contact Finish - Post: Tin
  • Contact Material: Phosphor Bronze
  • Insulation Material: Liquid Crystal Polymer (LCP)
  • Features: -
  • Operating Temperature: -55°C ~ 125°C
  • Ingress Protection: -
  • Material Flammability Rating: UL94 V-0
  • Insulation Color: Natural
  • Current Rating (Amps): -
  • Voltage Rating: 675VAC, 954VDC
