HCPL-814-W60E
Broadcom Limited
Broadcom Limited
OPTOISOLATOR 5KV TRANSISTOR 4DIP
$0.19
Available to order
Reference Price (USD)
20,900+
$0.16362
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Maximize your system's efficiency with HCPL-814-W60E Optoisolators by Broadcom Limited, designed for Photovoltaic Output applications. These isolators are perfect for isolating digital signals, protecting microcontrollers, and ensuring safe operation in high-voltage environments. Suitable for consumer electronics, aerospace, and defense applications, they deliver consistent performance under extreme conditions. Get started today contact us for more details and a customized solution!
Specifications
- Product Status: Active
- Number of Channels: 1
- Voltage - Isolation: 5000Vrms
- Current Transfer Ratio (Min): 20% @ 1mA
- Current Transfer Ratio (Max): 300% @ 1mA
- Turn On / Turn Off Time (Typ): -
- Rise / Fall Time (Typ): 4µs, 3µs
- Input Type: AC, DC
- Output Type: Transistor
- Voltage - Output (Max): 35V
- Current - Output / Channel: 50mA
- Voltage - Forward (Vf) (Typ): 1.2V
- Current - DC Forward (If) (Max): 50 mA
- Vce Saturation (Max): 200mV
- Operating Temperature: -30°C ~ 100°C
- Mounting Type: Through Hole
- Package / Case: 4-DIP (0.400", 10.16mm)
- Supplier Device Package: 4-DIP
