HCPL-7710-020
Broadcom Limited
Broadcom Limited
OPTOISO 5KV PUSH PULL 8DIP
$0.00
Available to order
Reference Price (USD)
1,100+
$3.13880
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Optimize your electronic designs with Broadcom Limited HCPL-7710-020 Optoisolators - Logic Output. These isolators deliver high-speed, reliable signal isolation with low power consumption and excellent thermal stability, ideal for applications in HVAC, lighting controls, and security systems. Trust Broadcom Limited for innovative solutions. Send us your requirements today!
Specifications
- Product Status: Discontinued at Digi-Key
- Number of Channels: 1
- Inputs - Side 1/Side 2: 1/0
- Voltage - Isolation: 5000Vrms
- Common Mode Transient Immunity (Min): 10kV/µs
- Input Type: Logic
- Output Type: Push-Pull, Totem Pole
- Current - Output / Channel: 10 mA
- Data Rate: 12.5MBd
- Propagation Delay tpLH / tpHL (Max): 40ns, 40ns
- Rise / Fall Time (Typ): 13ns, 5ns
- Voltage - Forward (Vf) (Typ): -
- Current - DC Forward (If) (Max): -
- Voltage - Supply: 4.5V ~ 5.5V
- Operating Temperature: -40°C ~ 100°C
- Mounting Type: Through Hole
- Package / Case: 8-DIP (0.300", 7.62mm)
- Supplier Device Package: 8-DIP
