FGB40N60SM
Fairchild Semiconductor
Fairchild Semiconductor
INSULATED GATE BIPOLAR TRANSISTO
$0.00
Available to order
Reference Price (USD)
800+
$2.38290
1,600+
$2.02800
2,400+
$1.93700
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Maximize energy efficiency with FGB40N60SM Single IGBTs by Fairchild Semiconductor, a trusted name in discrete semiconductors. Suitable for solar inverters, motor controllers, and more, these transistors feature low conduction loss and high switching frequency. Their robust design ensures long-term performance even in harsh environments. Choose FGB40N60SM for your next project and experience the Fairchild Semiconductor difference. Submit your inquiry today for expert assistance!
Specifications
- Product Status: Active
- IGBT Type: Field Stop
- Voltage - Collector Emitter Breakdown (Max): 600 V
- Current - Collector (Ic) (Max): 80 A
- Current - Collector Pulsed (Icm): 120 A
- Vce(on) (Max) @ Vge, Ic: 2.3V @ 15V, 40A
- Power - Max: 349 W
- Switching Energy: 870µJ (on), 260µJ (off)
- Input Type: Standard
- Gate Charge: 119 nC
- Td (on/off) @ 25°C: 12ns/92ns
- Test Condition: 400V, 40A, 6Ohm, 15V
- Reverse Recovery Time (trr): -
- Operating Temperature: -55°C ~ 175°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package: D2PAK (TO-263)
