CSDD-12N TR13
Central Semiconductor Corp
Central Semiconductor Corp
SCR 800V 12A D2PAK
$0.00
Available to order
Reference Price (USD)
1+
$0.00000
500+
$0
1000+
$0
1500+
$0
2000+
$0
2500+
$0
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
For high-performance Thyristors - SCRs, trust Central Semiconductor Corp's CSDD-12N TR13 to deliver exceptional results. Featuring high surge withstand capacity, low forward voltage drop, and reliable switching, these SCRs are ideal for phase controllers, soft starters, and protection circuits. Central Semiconductor Corp ensures every CSDD-12N TR13 meets global standards. Want to learn more or request a sample? Reach out today for fast, friendly service.
Specifications
- Product Status: Obsolete
- Voltage - Off State: 800 V
- Voltage - Gate Trigger (Vgt) (Max): 1.5 V
- Current - Gate Trigger (Igt) (Max): 15 mA
- Voltage - On State (Vtm) (Max): 1.6 V
- Current - On State (It (AV)) (Max): 24 A
- Current - On State (It (RMS)) (Max): 12 A
- Current - Hold (Ih) (Max): 20 mA
- Current - Off State (Max): 10 µA
- Current - Non Rep. Surge 50, 60Hz (Itsm): 110A @ 60Hz
- SCR Type: Sensitive Gate
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package: D2PAK
