AZ9422-1CE-24DEF
American Zettler
American Zettler
RELAY GEN PURPOSE SPDT 20A 24V
$1.59
Available to order
Reference Price (USD)
1+
$1.59000
500+
$1.5741
1000+
$1.5582
1500+
$1.5423
2000+
$1.5264
2500+
$1.5105
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The American Zettler AZ9422-1CE-24DEF series represents the next generation of high-amperage Power Relays, combining innovative coil designs with vibration-resistant mechanics. Ideal for harsh environments in marine, aerospace, and oil/gas industries. Features include LED operation indicators and solder/quick-connect terminals. Inquire about our relay customization services today!
Specifications
- Product Status: Active
- Mounting Type: Through Hole
- Coil Voltage: 24VDC
- Contact Form: SPDT (1 Form C)
- Contact Rating (Current): 20 A
- Switching Voltage: 277VAC, 30VDC - Max
- Coil Current: 15 mA
- Coil Type: Non Latching
- Features: -
- Termination Style: PC Pin
- Seal Rating: Sealed - Fully
- Coil Insulation: Class F
- Must Operate Voltage: 18 VDC
- Must Release Voltage: 2.4 VDC
- Operate Time: 10 ms
- Release Time: 5 ms
- Operating Temperature: -40°C ~ 85°C
- Contact Material: Silver Tin Oxide (AgSnO)
- Relay Type: General Purpose
