APT15GN120KG
Microsemi Corporation
Microsemi Corporation
IGBT 1200V 45A 195W TO220
$0.00
Available to order
Reference Price (USD)
1+
$0.00000
500+
$0
1000+
$0
1500+
$0
2000+
$0
2500+
$0
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Choose APT15GN120KG Single IGBTs by Microsemi Corporation for superior power handling in demanding environments. From railway systems to industrial drives, these transistors excel with features like avalanche ruggedness and integrated diodes. Their modular design simplifies installation and maintenance. Microsemi Corporation's reputation for quality makes APT15GN120KG a smart investment. Email us now for datasheets and volume discounts!
Specifications
- Product Status: Obsolete
- IGBT Type: Trench Field Stop
- Voltage - Collector Emitter Breakdown (Max): 1200 V
- Current - Collector (Ic) (Max): 45 A
- Current - Collector Pulsed (Icm): 45 A
- Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 15A
- Power - Max: 195 W
- Switching Energy: 410µJ (on), 950µJ (off)
- Input Type: Standard
- Gate Charge: 90 nC
- Td (on/off) @ 25°C: 10ns/150ns
- Test Condition: 800V, 15A, 4.3Ohm, 15V
- Reverse Recovery Time (trr): -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220 [K]
