ACS108-5SA-AP

Specifications

• Product Status: Obsolete
• Triac Type: Logic - Sensitive Gate
• Voltage - Off State: 500 V
• Current - On State (It (RMS)) (Max): 800 mA
• Voltage - Gate Trigger (Vgt) (Max): 1 V
• Current - Non Rep. Surge 50, 60Hz (Itsm): 7.3A, 8A
• Current - Gate Trigger (Igt) (Max): 10 mA
• Current - Hold (Ih) (Max): 25 mA
• Configuration: Single
• Operating Temperature: -30°C ~ 125°C (TJ)
• Mounting Type: Through Hole
• Package / Case: TO-226-3, TO-92-3 (TO-226AA) Formed Leads
• Supplier Device Package: TO-92-3
