8302401EA
Broadcom Limited
Broadcom Limited
OPTOISO 1.5KV 4CH DARLNG 16-DIP
$106.91
Available to order
Reference Price (USD)
1+
$88.63000
10+
$82.71900
25+
$81.24200
100+
$74.44710
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
Enhance circuit safety with 8302401EA Optoisolators from Broadcom Limited, featuring Photovoltaic Output for efficient signal transfer. Ideal for use in renewable energy systems, automotive electronics, and industrial machinery, these isolators provide excellent electrical isolation and noise reduction. Their compact design and high reliability make them a top choice for engineers worldwide. Ready to secure your components? Request a quote today and experience the Broadcom Limited difference!
Specifications
- Product Status: Active
- Number of Channels: 4
- Voltage - Isolation: 1500VDC
- Current Transfer Ratio (Min): 200% @ 5mA
- Current Transfer Ratio (Max): -
- Turn On / Turn Off Time (Typ): 2µs, 8µs
- Rise / Fall Time (Typ): -
- Input Type: DC
- Output Type: Darlington
- Voltage - Output (Max): 20V
- Current - Output / Channel: 40mA
- Voltage - Forward (Vf) (Typ): 1.4V
- Current - DC Forward (If) (Max): 10 mA
- Vce Saturation (Max): 110mV
- Operating Temperature: -55°C ~ 125°C
- Mounting Type: Through Hole
- Package / Case: 16-DIP (0.300", 7.62mm)
- Supplier Device Package: 16-DIP
