804-V3-084-12-002101

Preci-Dip

Manufacturer

Preci-Dip

Description:

CONN HEADER VERT 84POS 2.54MM

Datasheet:

804-V3-084-12-002101 Datasheet

$14.51

Available to order

Reference Price (USD)

50+

$10.74660

Exquisite packaging

Discount

TT / Paypal / Credit Card / Western Union / Money Gram

Discover high-quality 804-V3-084-12-002101 Preci-Dip Rectangular Connectors - Headers, Male Pins, designed for reliable and secure connections in various electronic applications. These connectors feature durable construction, excellent conductivity, and easy installation, making them ideal for industrial, automotive, and consumer electronics. Whether you need robust headers or precision male pins, our products ensure optimal performance. Contact us today for a quote and let us meet your connectivity needs!

Specifications

Product Status: Active
Connector Type: Header
Contact Type: Male Pin
Pitch - Mating: 0.100" (2.54mm)
Number of Positions: 84
Number of Rows: 3
Row Spacing - Mating: 0.100" (2.54mm)
Number of Positions Loaded: All
Style: Board to Board
Shrouding: Unshrouded
Mounting Type: Through Hole
Termination: Solder
Fastening Type: Push-Pull
Contact Length - Mating: 0.141" (3.60mm)
Contact Length - Post: 0.118" (3.00mm)
Overall Contact Length: 0.386" (9.80mm)
Insulation Height: 0.272" (6.91mm)
Contact Shape: Circular
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 29.5µin (0.75µm)
Contact Finish - Post: Tin
Contact Material: Brass
Insulation Material: Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features: -
Operating Temperature: -55°C ~ 125°C
Ingress Protection: -
Material Flammability Rating: UL94 V-0
Insulation Color: Black
Current Rating (Amps): 3A
Voltage Rating: 150VDC
