0010181090
Molex
Molex
CONN HEADER VERT 9POS 5.03MM
$3.96
Available to order
Reference Price (USD)
1+
$3.96000
500+
$3.9204
1000+
$3.8808
1500+
$3.8412
2000+
$3.8016
2500+
$3.762
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
The 0010181090 Molex Rectangular Connectors - Headers, Male Pins deliver precision and reliability for all your connectivity needs. Featuring gold-plated contacts, high-density layouts, and rugged housings, they excel in harsh environments. Perfect for military, automotive, and renewable energy applications. Let us help you find the right connector inquire now!
Specifications
- Product Status: Active
- Connector Type: Header
- Contact Type: Male Pin
- Pitch - Mating: 0.198" (5.03mm)
- Number of Positions: 9
- Number of Rows: 3
- Row Spacing - Mating: 0.198" (5.03mm)
- Number of Positions Loaded: All
- Style: Board to Board or Cable
- Shrouding: Shrouded - 4 Wall
- Mounting Type: Through Hole
- Termination: Solder
- Fastening Type: Latch Lock
- Contact Length - Mating: -
- Contact Length - Post: 0.170" (4.32mm)
- Overall Contact Length: -
- Insulation Height: 0.421" (10.70mm)
- Contact Shape: Circular
- Contact Finish - Mating: Tin
- Contact Finish Thickness - Mating: 200.0µin (5.08µm)
- Contact Finish - Post: Tin
- Contact Material: Cartridge Brass
- Insulation Material: Polyester
- Features: Board Guide
- Operating Temperature: -
- Ingress Protection: -
- Material Flammability Rating: UL94 V-0
- Insulation Color: Black
- Current Rating (Amps): -
- Voltage Rating: -
